#10442: New Clausing 15" x 50" C15 Series Manual Lathe
No longer available
#10442: New Clausing 15" x 50" C15 Series Manual Lathe
$31,330 (USD)
Location:Orange City, IA
Description
Inch dials Dead centers Coolant system One shot lubrication Interlocking chuck guard LED work light CE electrics Tool box and manual Splash guard Leadscrew cover Thread dial indicator t-slotted top slide Spindle brake magnetic geared head Spindle brake inverter variable speed head Roll out chip pan Chip guard Newall 2 axis DRO Installation of DRO
Specifications
| Manufacturer | Clausing |
| Model | 1550VSJ |
| Condition | New |
| Stock Number | 10442 |
| Swing over bed | 15.25” |
| Center height | 7.5” |
| Swing in gap | 24” |
| Swing over cross slide | 9.5” |
| Bed width | 11” |
| Spindle bore | 2.125” |
| Spindle nose | D1-6 |
| Spindle taper/bushing taper | 6 MT/4 MT |
| No spindle speeds | 3 |
| Spindle speed variable drive | 20-2500 |
| Cross slide travel | 9” |
| Cross slide width | 6.47” |
| Compound travel | 4.75” |
| Compound width | 4.01” |
| Max tool size | ¾” x ¾” |
| Tailstock quill diameter | 2.312” |
| Tailstock quill travel | 6.125” |
| Tailstock taper | 4 MT |
| Spindle motor | 7.5 HP |
| Coolant pump motor | 1/8 HP |
| Dimensions | 97” x 40” x 50” |
| Weight | 2,860 LBS |
