TRAK TRL 1845RX Lathe
Sold
TRAK TRL 1845RX Lathe
$59,557.75 (USD)
Location:Orange City, IA
Description
Equipped with:
Advanced features with Verify
Coolant pump
Work lamp
TRAKing option
Tooling kit, ¾” for TRL
10” Bison Chuck
Specifications
| Manufacturer | TRAK |
| Model | TRL 1845RX Lathe |
| Condition | New |
| Serial Number | 222EG572 |
| Stock Number | 10589 |
| Height of centers | 9" |
| Distance between centers | 45" |
| Swing over bed | 18.1" |
| Swing over saddle wings | 17" |
| Swing over cross slide | 9.13" |
| Cross slide travel | 10.6" |
| Tool section max | 1" |
| Coolant tank capacity | 13 gallons |
| Width of bed | 13.4" |
| Height of bed | 12.4" |
| Spindle nose (Camlock) | D1-6 |
| Spindle throug hole | 2.36" |
| Spindle taper | MT #6 |
| Taper in reduction sleeve | MT #4 |
| Spindle diameter at front bearing | 3.35" |
| Number of bearings | 2 |
| Spindle speed range | 80-850, 250-2500 RPM |
| Tailstock quill travel | 6" |
| Quill diameter | 2.56" |
| Quill taper hole | MT #4 |
| Spindle motor | 10 HP |
| Power requirement, control | 110V, 1 PH, 10 A |
| Power requirements, machine | 220V, 3 PH, 60 Hz |
| Maximum rapid feed X | 100 |
| Maximum rapid feed Z | 250 |
| Coolant pump motor | 1/8 HP |
| Approximate overall dimensions | 94" x 52" x 73" |
| Approximate weight | 3,800 LBS |
