Clausing "The Professional" 21" Variable Speed Lathe 8115VSJ

No longer available

Clausing "The Professional" 21" Variable Speed Lathe 8115VSJ

$53,575 (USD)

Location:Orange City, IA

Description

Equipped with:

Spindle center bushing

Two MT dead centers

Splash guard

Chuck guard

Leadscrew cover

Coolant system

Inch threading dial

Set of wrenches and keys

Instruction and parts manual

Accuracy chart

Emergency stop button

Lockable isolator switch

One shot saddle and cross slide lubrication

Forward/reverse/stop switch

Standard 230/3/60 or 460/3/60 volts


Specifications

ManufacturerClausing "The Professional" 21" Variable Speed Lathe
Model8115VSJ
ConditionNew
Serial NumberWF5029
Stock Number10669
Height of center11.02"
Swing over bed21.81"
Swing in gap32.68"
Length of bed60"
Width in front of faceplate8.5"
Swing over cross slide14.57"
Bedway width15.75"
Spindle bore4.09"
Spindle nose (camlock)D1-11
Spindle nose taper5MT
Number of spindle speeds3 infinitely variable
Spindle speed range18-1800 RPM
Travel of cross slide11.81"
Width of cross slide8"
Travel of top slide7.5"
Width of top slide4"
Quill travel5.7"
Quill diameter3.74"
Quill taper6MT
Longitudinal feed range0.0016-0.11 in/rev
Cross feed range0.0008-0.055 in/rev
Spindle motor15 HP
