Hyd-Mech S-20A 13" x 18" Horizontal Automatic Bandsaw S-20A
Hyd-Mech S-20A 13" x 18" Horizontal Automatic Bandsaw S-20A
$45,000 (USD)
Location:Orange City, IA
orCall 712-737-8700
Description
Equipped with:
Full capacity hydraulic overhead bundling
Variable vise pressure
Flood coolant
Laser light
Work light
Specifications
| Manufacturer | Hyd-Mech S-20A 13" x 18" Horizontal Automatic Bandsaw |
| Model | S-20A |
| Condition | New |
| Serial Number | 100000000001579 |
| Stock Number | 10862 |
| Capacity rectangle at 90 degrees | 13" x 18" |
| Capacity round at 90 degrees | 13" |
| Capacity rectangle at 45 degrees | 13" x 10 3/4" |
| Capacity round at 45 degrees | 12" |
| Capacity rectangle at 30 degrees | 13" x 7 3/4" |
| Capacity round at 30 degrees | 8-1/2" |
| Blade size | 1" x 14' 10" |
| Blade drive | 5 HP, VFD |
| Machine voltage | 208-480V, 3 PH |
| Blade speeds | 75-350 SFM |
| Coolant tank capacity | 12 gallons |
| Work load | 5,000 LBS |
| Machine weight | 3,800 LBS |
| Table height | 31" |
| Dimensions | 93" x 86" x 52" |
